Scanning
Type Handheld bar code reader
Scanner type 1D
Sensor type Laser
Linear (1D) barcodes supported Codabar, Code 11, Code 128, Code 39 (ASCII), Code 93, GS1 DataBar, Pharmacode, Plessey, Standard 2 of 5
Scanner resolution 3 mm
Working distance 63.5 cm
Read rate (max) 100 reads/s
Light levels (direct sunlight) 0 - 86080 lx
Wavelength 650 nm
Tilt reading angle -10 - 10°
Pitch reading angle -65 - 65°
Yaw reading angle -60 - 60°
Ports & interfaces
Connectivity technology Wired
Standard interfaces RS-232, RS-485, Keyboard wedge, USB
Performance
International Protection (IP) code IP30
Protection features Drop resistant, Scratch resistant
LED indicators Yes
Product colour Black, White
Certification EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + AC 2011; IEC 60950-1: 2005 + A1: 2009; UL 60950-1, second edition; CAN/CSA-C22.2 No. 60950-1-07 FCC 47 CFR Part 15, Subpart B, Class B; ICES-003 Issue 4, Class B; Compliant with EMC Directive 2004/108/EC CDRH Class II; IEC Class 2
Power
Power source type DC
Input voltage 4.5 - 5.5 V
Power consumption 175 mA
Weight & dimensions
Width 64 mm
Depth 85 mm
Height 152 mm
Weight 150 g
Packaging data
Cables included USB
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Storage temperature (T-T) -40 - 70 °C
Operating relative humidity (H-H) 5 - 95%
Drop resistance 0.5 m
Technical details
Compliance certificates Federal Communications Commission (FCC), RoHS
