Conference rooms and home theaters require reliable audio and video transmission over distances. The Siig AV Extender connects your equipment seamlessly up to 30 meters, ensuring high-definition quality.
Capable of delivering crisp 1920 x 1200 pixel resolution while maintaining HDCP compliance, this wired solution provides a stable connection free from interference. Perfect for multimedia settings, you can trust the Siig AV Extender to enhance your viewing experience.
- Resolution: 1920 x 1200 pixels
- Transmission Distance: Up to 30 meters
- Connection Type: Wired
- Color: White
- HDCP Compliant: Yes
Ideal for AV professionals, event coordinators, and businesses requiring dependable HD video transmission for large spaces.
Available stock: 7
Couldn't load pickup availability
-
Estimated delivery: Jun 14 - Jun 18
Share this product
Infomations
Infomations
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
| Features | |
|---|---|
| Type | AV transmitter & receiver |
| Maximum resolution | 1920 x 1200 pixels |
| Maximum transfer distance | 30 m |
| LED indicators | Yes |
| Supported graphics resolutions | 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1360 x 768 (WXGA), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA) |
| Bandwidth | 10.2 Gbit/s |
| HDCP | Yes |
| HDCP version | 1.4 |
| Product colour | White |
| HDBaseT certified | Yes |
| Certification | FCC, CE |
| Ports & interfaces | |
| Connectivity technology | Wired |
| RJ-45 input ports | 1 |
| HDBaseT port | Yes |
| VGA (D-Sub) input ports | 1 |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| HDMI version | 1.4 |
| USB ports quantity | 2 |
| USB connector type | Micro-USB B, USB Type-B |
| Remote (IR) output | 1 |
| DC-in jack | Yes |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Operating voltage | 24 V |
| Output current | 2.71 A |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 114 mm |
| Depth | 34 mm |
| Height | 70 mm |
| Weight | 140 g |
| Receiver dimensions (WxDxH) | 250 x 130 x 31 mm |
| Receiver weight | 1.5 kg |
| Transmitter dimensions (WxDxH) | 105 x 44 x 89 mm |
| Transmitter weight | 240 g |
| Packaging content | |
| AC adapter included | Yes |
| Cables included | USB Type-A to USB Type-B |
| IR emitter included | Yes |
| Manual | Yes |
| Mounting kit | Yes |
| Technical details | |
| Compliance certificates | RoHS |
