Features
2.4 GHz Yes
5 GHz Yes
Maximum data transfer rate 5950 Mbit/s
Maximum data transfer rate (2.4 GHz) 1150 Mbit/s
Maximum data transfer rate (5 GHz) 4800 Mbit/s
Ethernet LAN data rates 5000 Mbit/s
Frequency band 20/40 (2.4 GHz), 20/40/80/(80+80) (5 GHz), and maximum peak data rate 5.37 Gbps
Networking standards IEEE 802.11ax, IEEE 802.11mc
Auto MDI/MDI-X Yes
MIMO Yes
Spread spectrum method DSSS, OFDM
Modulation 16PSK, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK
Security
Security algorithms WMM, WPA, WPA2
Ports & interfaces
Ethernet LAN (RJ-45) ports 2
USB 2.0 ports quantity 1
USB connector type USB Type-A
Power
Power over Ethernet (PoE) Yes
Power consumption (max) 38.2 W
Design
Placement Ceiling
Product colour White
Cable lock slot Yes
Cable lock slot type Kensington
Recommended usage Indoor
Antenna
Antenna type Internal
Antenna direction type Omni-directional
Antenna features Integrated antenna
Antennas quantity 4
Antenna gain level (max) 5.5 dBi
Performance
Compatible operating systems HPE Aruba Networking Wireless Operating System 10.0.0.0 or later HPE Aruba Networking Wireless Operating System 8.5.0.0* HPE Aruba Networking Instant OS 8.5.0.0* Note: *With some restrictions. For unrestricted operation, use 8.6.0.0 or later.
Certificates
Compliance certificates Federal Communications Commission (FCC), ISED, CE, Electromagnetic Compatibility (EMC)
Certification UL2043 plenum rating Wi‑Fi Alliance: Wi-Fi CERTIFIED a, b, g, n, ac, ax WPA, WPA2, and WPA3—Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, W-Fi Agile Multiband Passpoint (Release 2) Wi-Fi CERTIFIED Location Bluetooth Special Interest Group (SIG)
Weight & dimensions
Width 260 mm
Depth 260 mm
Height 58 mm
Weight 1.57 kg
Other features
I/O ports E0, E1: Ethernet port (RJ-45) Serial console interface (proprietary, micro-B USB physical jack) USB 2.0 host interface (Type A connector) Kensington security slot
Weight (imperial) 1.57 kg (3.46 lbs)
Operational conditions
Operating relative humidity (H-H) 5 - 93%
Operating temperature (T-T) 0 - 50 °C
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 5 - 93%
