Data transmission
Firewall throughput 202.5 Mpps
Firewall throughput 239 Gbit/s
IPSec VPN throughput 160 Gbit/s
IPS/IDS throughput 170000 Mbit/s
Threat protection throughput 100000 Mbit/s
SSL inspection throughput 110000 Mbit/s
Firewall latency 4.8 µs
Security policies (max) 200000
Performance
Built-in processor Yes
Heat dissipation 5350 BTU/h
Concurrent connections 200000000
Noise level 57.43 dB
Network
Concurrent SSL/VPN connections (maximum) 30000
Security
Domains quantity 500
Management features
LED indicators Yes
Management platform FortiOS
Ports & interfaces
Connectivity technology Wired
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 1
Ethernet LAN (RJ-45) ports 2
Ethernet LAN data rates 1000,100 Mbit/s
Console port RJ-45
SFP module slots quantity 24
SFP+ module slots quantity 3
DC-in jack Yes
Storage
Storage media type SSD
Total storage capacity 2 TB
SSD capacity 1 TB
Number of SSDs installed 2
Design
Rack mounting Yes
Form factor 3U
Built-in fan Yes
Number of fans 3 fan(s)
Power
Input current 32 A
DC input voltage -48 - 60 V
Power consumption (typical) 1328 W
Power consumption (max) 1568 W
Redundant power supply (RPS) support Yes
Certificates
Certification FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -35 - 70 °C
Operating relative humidity (H-H) 10 - 90%
Operating altitude 0 - 2250 m
Weight & dimensions
Width 437 mm
Depth 694 mm
Height 133 mm
Weight 36.1 kg
Packaging content
Transceiver(s) included Yes
Number of transceivers 2
Other features
Firewall throughput 239000 Mbit/s
