Management features
Switch type Managed
Switch layer L2/L3
Quality of Service (QoS) support Yes
Web-based management Yes
Cloud-managed Yes
ARP inspection Yes
Configuring Location Settings (CLI) Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 48
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
SFP module slots quantity 2
SFP+ module slots quantity 4
Uplink ports quantity 4
Console port RJ-45/Micro-USB
USB 2.0 ports quantity 2
Network
Networking standards IEEE 802.3at
10G support Yes
Copper ethernet cabling technology 1000BASE-T
Full duplex Yes
IP routing Yes
Half duplex Yes
IP address table 16000
Ethernet LAN data rates 10,100,1000 Mbit/s
Auto-sensing Yes
IPv4 routes 12000
IPv6 routes 6000
VLAN support Yes
Number of VLANs 4094
Data transmission
Switching capacity 256 Gbit/s
Forwarding rate 190.5 Mpps
MAC address table 32000 entries
Number of queues 8
Number of IP interfaces 1533
Security
Access Control List (ACL) Yes
Access Control List (ACL) egress 1024
Access Control List (ACL) ingress 8000
Multicast features
Multicast support Yes
IPv4 multicast entries 6000
Design
Rack mounting Yes
Stackable Yes
Product colour Purple
Performance
Noise level 41.3 dB
Power
Power source AC
Power supply included Yes
Number of power supply units 1
AC input voltage 100 - 240 V
AC input frequency 47/63 Hz
Power consumption (max) 1674 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) ports quantity 48
Power over Ethernet (PoE) power per port 30 W
Total Power over Ethernet (PoE) budget 740 W
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Storage temperature (T-T) -40 - 70 °C
Operating relative humidity (H-H) 10 - 95%
Storage relative humidity (H-H) 10 - 95%
Operating altitude 0 - 3000 m
Heat dissipation 663 BTU/h
Weight & dimensions
Width 441 mm
Depth 330 mm
Height 44 mm
Weight 5.28 kg
Certificates
Certification CISPR 32, Class A (International Emissions) AS/NZS CISPR32 CISPR 24 Class A (International Immunity) IEC 61000-4-2 / EN 61000-4-2 Electrostatic Discharge, 8kV Contact, 15 kV Air, Criteria B IEC 61000-4-3 /EN 61000-4-3 Radiated Immunity 10V/m, Criteria A IEC 61000-4-4 / EN 61000-4-4 Transient Burst, 2 kV, Criteria B IEC 61000-4-5 /EN 61000-4-5 Surge, 2 kV L-L, 2 kV L-G, Level 3, Criteria B IEC 61000-4-6 Conducted Immunity, 0.15-80 MHz, 10V/rms, 80%AM (1kHz), Criteria A IEC/EN 61000-4-11 Power Dips & Interruptions, >30%, 25 periods, Criteria C
