Features
2.4 GHz Yes
5 GHz Yes
6 GHz No
Maximum data transfer rate 2400 Mbit/s
Maximum data transfer rate (2.4 GHz) 600 Mbit/s
Maximum data transfer rate (5 GHz) 2400 Mbit/s
Ethernet LAN data rates 10,100,1000,2500 Mbit/s
Frequency band 2.4 - 5.85 GHz
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Number of users 128 user(s)
Bluetooth No
MIMO Yes
MIMO type Multi User MIMO
Spatial streams 2 x 2
Spread spectrum method DSSS, OFDM, OFDMA
Wi-Fi Multimedia (WMM)/(WME) Yes
Wi-Fi roaming Yes
Fast roaming Yes
VLAN support Yes
Virtual LAN features Tagged VLAN
Quality of Service (QoS) support Yes
Maximum Tx power (2.4 GHz) 21 dBmW
Maximum Tx power (5 GHz) 21 dBmW
Security
Security algorithms WPA2-PSK, WPA3-PSK
MAC address filtering Yes
Service Set Identifier (SSID) features Hidden SSID
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
DC-in jack Yes
Power
Power over Ethernet (PoE) Yes
DC voltage range 12 V
Input current 1.5 A
Power consumption (max) 10.7 W
Design
Placement Ceiling, Wall
Product colour White
Antenna
Antenna type Internal
Antenna direction type Omni-directional
Antenna features Integrated antenna
Antennas quantity 4
Antenna gain level (max) 7 dBi
Performance
Built-in processor Yes
Processor model ARM Cortex-A53
Processor frequency 1000 MHz
Certificates
Compliance certificates CE, Federal Communications Commission (FCC), Industry Canada (IC), UKCA
Weight & dimensions
Width 160 mm
Depth 160 mm
Height 30 mm
Weight 380 g
Packaging data
Package width 266 mm
Package depth 165 mm
Package height 39 mm
Package weight 500 g
Packaging content
Mounting kit Yes
Operational conditions
Operating relative humidity (H-H) 0 - 90%
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -40 - 80 °C
Storage relative humidity (H-H) 0 - 90%
Logistics data
Harmonized System (HS) code 85176990
Master (outer) case width 353 mm
Master (outer) case length 428 mm
Master (outer) case height 311 mm
Master (outer) case gross weight 12.2 kg
Products per master (outer) case 20 pc(s)
