Management features
Switch type Unmanaged
Quality of Service (QoS) support Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 24
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Power connector AC-in jack
Network
Networking standards IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
10G support No
Copper ethernet cabling technology 10BASE-T, 100BASE-T, 1000BASE-T
Cable types supported Cat3, Cat4, Cat5, Cat5e
Full duplex Yes
Flow control support Yes
Broadcast storm control Yes
Auto MDI/MDI-X Yes
Active link detection Yes
MAC address auto-learning supported Yes
MAC address auto-aging supported Yes
Data transmission
Switching capacity 48 Gbit/s
Forwarding rate 35.71 Mpps
MAC address table 8000 entries
Store-and-forward Yes
Number of queues 8
Jumbo frames support Yes
Jumbo frames 10000
Packet forwarding rate (1 Gbps) 14880 pps
Packet forwarding rate (100 Mbps) 148800 pps
Packet forwarding rate (10 Mbps) 1488000 pps
Packet buffer memory 0.5 MB
Design
Rack mounting Yes
Stackable Yes
Form factor 1U
Product colour Black, Silver
Housing material Metal
LED indicators Activity, Link, Power, Speed
Electromagnetic compatibility ICES-003 Class A, FCC Class A, RCM Class A, BSMI Class A, CE Class A, VCCI A, CCC, KCC
Performance
Noise level 0 dB
Mean time between failures (MTBF) 863100 h
Power
Power supply included Yes
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Input current 0.3 A
Power consumption (max) 13.3 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -10 - 70 °C
Operating relative humidity (H-H) 0 - 95%
Storage relative humidity (H-H) 0 - 95%
Heat dissipation 45.35 BTU/h
Weight & dimensions
Width 280 mm
Depth 180 mm
Height 44 mm
Weight 1.3 kg
Certificates
Certification cUL/UL CE LVD CCC CB BSMI
