Features
Module type Digital
Signal direction Input/output
Channels quantity 4 channels
Digital input channels quantity 4 channels
Digital output channels quantity 4 channels
Serial interface type RS-232
Ethernet LAN (RJ-45) ports 1
I/O protocols Modbus TCP or DCON ASCII (over TCP or Virtual COM port)
Supported network protocols ICMP, IP, TCP, DHCP, HTTP
Maximum output voltage 30 V
Maximum output current per channel 0.85 A
Maximum combined load 3.4 A
Electrostatic Discharge (ESD) protection 16 kV
Isolation 1.5 kV
Overheat protection Yes
Overheat shutdown (typical) 175 °C
Overheat shutdown (min) 150 °C
Short circuit protection Yes
Short circuit protection up to 36 V
Quick-Stop function Yes
Windows operating systems supported Windows 10, Windows 2000, Windows 7, Windows 7 x64, Windows 8, Windows 8 x64, Windows Vista, Windows Vista x64, Windows XP, Windows XP x64
Linux operating systems supported Yes
Mac operating systems supported Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Mobile operating systems supported Android, iOS
Product colour Black, Purple
Power
Power consumption 100 mA
Power consumption note 2.5W Max: 220mA @+5VDC / 36mA @+30VDC
DC input voltage 5 - 30 V
Maximum input voltage 35 V
Power supply type 1: PW-600, 2: PW-650
Operational conditions
Operating temperature (T-T) 0 - 60 °C
Storage temperature (T-T) 0 - 70 °C
Weight & dimensions
Width 116 mm
Depth 100 mm
Height 26 mm
Weight 126 g
Package width 160 mm
Package depth 135 mm
Package height 49 mm
Package weight 222 g
