Technical details
Type Basic access control reader
Authentication type Access chip/card, Password
Vandal-proof Yes
LED indicators Yes
Built-in relay No
Authentication card type MIFARE Classic, MIFARE DESFire EV1, MIFARE DESFire EV2, MIFARE Plus
Tamper protection Yes
Fingerprint reader No
Access code reader Yes
Access chip/card reader Yes
Access chip/card reader type Contactless
Keypad integrated Yes
Keypad number of keys 12
Keypad illumination Yes
RFID frequency 13.56 MHz
Recommended usage Outdoor
Open Supervised Device Protocol (OSDP) Yes
Compliance certificates CE, UL, Federal Communications Commission (FCC), ICES, Electromagnetic Compatibility (EMC), RCM, RoHS
Product colour Black
International Protection (IP) code IP65, IP66
IK code IK07
Warranty period 5 year(s)
Certification EAL6+
Display
Built-in display No
Camera
Front camera No
Ports & interfaces
Wi-Fi No
Bluetooth No
PC connected No
RS-485 ports 1
Alarm input/output No
Power
Input voltage 12 V
Power over Ethernet (PoE) No
DC current (max) 0.134 A
Weight & dimensions
Width 85 mm
Depth 27 mm
Height 121 mm
Weight 258 g
Operational conditions
Operating temperature (T-T) -40 - 65 °C
Operating relative humidity (H-H) 10 - 100%
Storage temperature (T-T) -40 - 65 °C
Storage relative humidity (H-H) 5 - 95%
Sustainability
Doesn't contain Lead, Mercury, Cadmium
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance Yes
