Scanning
Type Handheld bar code reader
Scanner type 1D/2D
Sensor type CMOS
Linear (1D) barcodes supported Codabar, Code 11, Code 128, Code 25 (IR 2 of 5), Code 25 (non-IR 2 of 5), Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar, GS1-128 (UCC/EAN-128), MSI, Plessey, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported Data Matrix, Micro QR Code, PDF417, QR Code
Optical sensor resolution (W x H) 640 x 480 pixels
Working distance 30 cm
Light levels (direct sunlight) 0 - 100000 lx
Wavelength 650 nm
Tilt reading angle -50 - 50°
Pitch reading angle -45 - 45°
Yaw reading angle -360 - 360°
Motion tolerance (cm/s) 60.96
Ports & interfaces
Connectivity technology Wired
Standard interfaces USB
Cable length 1.83 m
Performance
Housing material Plastic, Silicone
International Protection (IP) code IP67
Protection features Shock resistant, Waterproof
LED indicators Yes
Buzzer Yes
Product colour Yellow
Country of origin China
Certification FCC, CE
Power
Power source type USB
Input voltage 5 V
Power consumption 220 mA
Weight & dimensions
Width 72 mm
Depth 100 mm
Height 175 mm
Weight 160 g
Packaging data
Package width 215.9 mm
Package depth 114.3 mm
Package height 88.9 mm
Package weight 453.5 g
Operational conditions
Operating temperature (T-T) -20 - 50 °C
Storage temperature (T-T) -40 - 70 °C
Operating relative humidity (H-H) 5 - 95%
Technical details
Compliance certificates RoHS
Logistics data
Harmonized System (HS) code 84716070
Other features
Compatible operating systems Windows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP, Mac OS X
