Management features
Switch type Managed
Switch layer L3
Quality of Service (QoS) support Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 16
Basic switching RJ-45 Ethernet ports type 10G Ethernet (100/1000/10000)
Console port RJ-45/Mini-USB
USB 2.0 ports quantity 1
Network
Networking standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u
10G support Yes
Port mirroring Yes
IP routing Yes
Link aggregation Yes
Auto-sensing Yes
VLAN support Yes
Virtual LAN features Private VLAN, Tagged VLAN, Voice VLAN
Number of VLANs 4093
Data transmission
Switching capacity 320 Gbit/s
Throughput 238 Mpps
MAC address table 16000 entries
Store-and-forward Yes
Number of queues 8
Number of static routes 64
Jumbo frames support Yes
Jumbo frames 9000
Security
DHCP features DHCP client, DHCP snooping, DHCPv6 client, DHCPv6 relay, DHCPv6 server, DHCPv6 snooping
Access Control List (ACL) Yes
IGMP snooping Yes
BPDU filtering/protection Yes
Authentication Guest VLAN, MAC-based authentication
Multicast features
Multicast support Yes
Number of multicast groups filtered 4000
Protocols
GARP VLAN Registration Protocol (GVRP) Yes
Routing protocols OSPF, OSPFv3, RIP, RIP-1, RIP-2
Design
Rack mounting Yes
Stackable Yes
Form factor 1U
Product colour Black
Airflow direction Front-to-back airflow
Performance
Physical stacking (units) 8
Built-in processor Yes
Processor frequency 800 MHz
Internal memory 1024 MB
Noise level 35 dB
Mean time between failures (MTBF) 690301 h
Power
Power supply included Yes
Number of power supply units 1
Power consumption (max) 610 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) Yes
Power over Ethernet plus (PoE+) ports quantity 16
Power over Ethernet (PoE) power per port 30 W
Total Power over Ethernet (PoE) budget 500 W
Operational conditions
Heat dissipation 2081.64 BTU/h
Weight & dimensions
Width 212 mm
Depth 345 mm
Height 44 mm
Weight 3.22 kg
Packaging content
Rack mount kit Yes
Logistics data
Harmonized System (HS) code 85176990
