Newland HR33 Marlin
Newland HR33 Marlin
1 people are viewing this product
Regular price
£68.69 GBP
Sale price
£68.69 GBP
Regular price
£85.86 GBP
Shipping calculated at checkout.
Newland HR33 Marlin, Handheld bar code reader, 1D/2D, CMOS, AIM-128, China Post, Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 Composite,..., Aztec Code, Code 1, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, China Travel Permit OCR, Chinese ID Card, Passport OCR
Available stock: 311
-
Estimated delivery: Jul 11 - Jul 15
Share this product
Couldn't load pickup availability
Informations
Informations
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
| Scanning | |
|---|---|
| Type | Handheld bar code reader |
| Scanner type | 1D/2D |
| Sensor type | CMOS |
| Linear (1D) barcodes supported | AIM-128, China Post, Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 Composite, GS1 DataBar, GS1 DataBar Coupon, GS1-128 (UCC/EAN-128), ISBN, ISSN, ITF-14, ITF-6, Industrial 2 of 5, Interleaved 2 of 5, MSI-Plessey, Matrix 2 of 5, Plessey, Standard 2 of 5, UPC-A, UPC-E |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Code 1, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code |
| OCR types supported | China Travel Permit OCR, Chinese ID Card, Passport OCR |
| Laser guide | Yes |
| Optical sensor resolution (W x H) | 1280 x 800 pixels |
| Horizontal field of view | 48° |
| Vertical field of view | 30° |
| Tilt reading angle | 0 - 360° |
| Pitch reading angle | 0 - 60° |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Standard interfaces | RS-232, USB |
| USB 2.0 ports quantity | 1 |
| Performance | |
| International Protection (IP) code | IP52 |
| LED indicators | Yes |
| Buzzer | Yes |
| Print contrast | 15% |
| Product colour | Black |
| Vibration function | Yes |
| Certification | IEC62471, IEC60825 |
| Power | |
| Power source type | USB |
| Power consumption | 281 mA |
| Weight & dimensions | |
| Width | 95 mm |
| Depth | 68 mm |
| Height | 166 mm |
| Weight | 140 g |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Drop resistance | 1.5 m |
| Technical details | |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
