j5create JCD542
j5create JCD542
Available stock: 3
-
Estimated delivery: Jul 11 - Jul 15
Share this product
Couldn't load pickup availability
Informations
Informations
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
| Ports & interfaces | |
|---|---|
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 100 W |
| HDMI ports quantity | 2 |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Network | |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Performance | |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), SD |
| HD type | 4K Ultra HD |
| Number of displays supported | 2 |
| Maximum refresh rate | 30 Hz |
| Product colour | Black, Grey |
| Hub interfaces | 3.5mm, HDMI, RJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| Housing material | Aluminium |
| Country of origin | Taiwan |
| Power | |
| Power supply type | USB |
| Output voltage | 20 V |
| Output current | 0.9 A |
| Power consumption (typical) | 4.5 W |
| Software | |
| Windows operating systems supported | Windows 10 |
| Mac operating systems supported | Mac OS X 10.11 El Capitan |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 65 °C |
| Weight & dimensions | |
| Width | 82.5 mm |
| Depth | 350.2 mm |
| Height | 22 mm |
| Weight | 307 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 88.3 mm |
| Package depth | 358 mm |
| Package height | 28 mm |
| Package weight | 405 g |
| Packaging content | |
| Cables included | USB Type-C |
| Quick start guide | Yes |
| Manual | Yes |
| Packaging content | 1 x JCD542 USB-C® Dual HDMI™ Docking Station, 1 x Quick Installation Guide (QIG) |
| Technical details | |
| Warranty period | 2 year(s) |
| Other features | |
| Cable length | 0.45 m |
| Maximum operating temperature | 40 °C |
