Ports & interfaces
Connectivity technology Wired
Host interface PCI Express
Interface Fiber
Ethernet LAN (RJ-45) ports 2
Fiber ports quantity 2
Fiber optic connector SFP+
PCI version 3.0
PCI Card form factor Full-height (low-profile)
Network
Maximum data transfer rate 10000 Mbit/s
Networking standards IEEE 802.1as, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ad
Ethernet LAN Yes
Ethernet interface type Gigabit Ethernet, 10 Gigabit Ethernet
Ethernet LAN data rates 1000,10000 Mbit/s
Fiber ethernet cabling technology 10GBASE-LR, 10GBASE-SR
Supported network protocols TCP, UDP, IP
VLAN tagging Yes
Maximum operating distance 10 m
LAN controller Intel® X710
Design
Product colour Black, Green
Internal Yes
Chipset X710-AM2
LED indicators Yes
Certification FCC B, UL, CE, VCCI, BSMI, CTICK, KCC
Power
Power consumption (typical) 4.5 W
System requirements
Compatible operating systems https://www.intel.com/content/www/us/en/support/articles/000025890/network-and-i-o/ethernet-products.html
Linux operating systems supported RedHat EL Linux 6.0
Other operating systems supported FreeBSD
Server operating systems supported Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Operational conditions
Operating temperature (T-T) 0 - 55 °C
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 35 - 90%
Weight & dimensions
Width 68.6 mm
Depth 167.1 mm
Logistics data
Harmonized System (HS) code 85176990
Other features
Cable type SFP+ Direct Attached Twinaxial Cabling up to 10m
Market segment Server
Target market Artificial Intelligence, High Performance Computing
Flow control support Yes
Management protocols PXE, SNMP, RMON
Number of VLANs 4096
Intel® Virtualization Technology (Intel® VT) VT-c
Intel Trusted Execution Technology No
Embedded options available No
Intel Virtual Machine Device Queues (VMDq) Yes
PCI-SIG* SR-IOV Capable Yes
On-chip QoS and Traffic Management Yes
Intel Flexible Port Partitioning Yes
Speed & slot width 8.0 GT/s, x8 Lane
Intelligent Offloads Yes
iWARP/RDMA No
Intel Ethernet Power Management Yes
Intel Data Direct I/O Technology Yes
Intel Virtualization Technology for Connectivity (VT-c) Yes
Interface type PCIe v3.0 (8.0 GT/s)
Launch date Q4'14
Network interface card cable medium Copper
Product type Network Interface Card
Status Launched
Last change 64826824
Processor family 700 Network Adapters (up to 40GbE)-700 Network Adapters (up to 40GbE)
Export Control Classification Number (ECCN) 5A991
Commodity Classification Automated Tracking System (CCATS) NA
Controller type Intel® Ethernet Controller X710
Cabling type SFP+ Direct Attached Twinaxial Cabling up to 10m
Bracket height Low-Profile (LP) / Full-Height (FH)
Product family Intel 10 Gigabit server adapter
Product series 700 Series Network Adapters (up to 40GbE)
Product codename Fortville
