Processor
Processor manufacturer Intel
Processor family Intel® Xeon®
Processor model 6505P
Processor frequency 2.2 GHz
Processor boost frequency 4.1 GHz
Processor cores 12
Processor cache 48 MB
Number of processors installed 1
Processor cache type L3
Memory
Internal memory 64 GB
Internal memory type DDR5-SDRAM
Memory slots 32x DIMM
Memory clock speed 6400 MHz
Memory layout (slots x size) 2 x 32 GB
Maximum internal memory 8 TB
Storage
Total storage capacity 960 GB
Number of SSDs installed 2
SSD capacity 480 GB
SSD interface SATA III
Supported SSD sizes 2.5"
Number of SSDs supported 8
RAID support Yes
Supported RAID controllers HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
Optical drive type No
Graphics
On-board graphics card No
On-board graphics card model Not available
Network
LAN controller Broadcom BCM57416
Ethernet LAN Yes
Ethernet interface type 10 Gigabit Ethernet
Ports & interfaces
Ethernet LAN (RJ-45) ports 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3
Expansion slots Maximum 3 PCIe Gen5 slots (x16 lanes/each) & Maximum 2 OCP3.0 slots (x16 lanes/each)
VGA (D-Sub) ports quantity 1
Number of management ports 1 pc(s)
Design
Chassis type Rack (1U)
Cooling type Active
Rack mounting Yes
Performance
Management platform Included - HPE iLO7 Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download). Optional - HPE iLO7 Advanced, and HPE OneView Advanced. Refer to the iLO 7 User Guide
Software
Operating system installed No
Power
Power supply type 2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Redundant power supply (RPS) support Yes
Power supply 1000 W
Number of main power supplies 2
Weight & dimensions
Width 753.1 mm
Depth 434.6 mm
Height 42.9 mm
Other features
Standard fans 5x Standard Fans
Storage drive type 2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
Security features UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. Optional Trusted Supply Chain, iLO Security modes, Chassis Intrusion detection and Bezel Locking kits. For full security features refer to the QuickSpecs.
Number of processors supported 1
