Elo Touch Solutions I-Series 5
Elo Touch Solutions I-Series 5Available stock: 10
-
Estimated delivery: Sep 29 - Oct 03
Share this product
Couldn't load pickup availability
Informations
Informations
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
| Display | |
|---|---|
| Panel type | TFT-LCD |
| Display diagonal | 25.6 cm (10.1") |
| Display technology | LED |
| Display resolution | 920 x 1200 pixels |
| Display brightness | 450 cd/m² |
| Touchscreen | Yes |
| Touchscreen technology | Projected capacitive system |
| Multi-touch | Yes |
| Response time | 30 ms |
| Contrast ratio (typical) | 900:1 |
| Viewing angle, horizontal | 160° |
| Viewing angle, vertical | 160° |
| Display number of colours | 16.7 million colours |
| Active display area (W x H) | 217 x 136 mm |
| Display diagonal (metric) | 256.54 cm |
| Number of displays | 1 |
| Native refresh rate | 60 Hz |
| Ports & interfaces | |
| USB port | Yes |
| USB ports quantity | 5 |
| USB connector type | Micro-USB, USB Type-C |
| Ethernet LAN (RJ-45) ports | 1 |
| Compatible memory cards | MicroSD (TransFlash) |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 4 W |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| Screen shape | Flat |
| VESA mounting | Yes |
| Panel mounting interface | 75 x 75 mm |
| Performance | |
| Purpose | Commercial |
| Number of microphones | 2 |
| Mean time between failures (MTBF) | 50000 h |
| Power | |
| Power consumption (typical) | 6 W |
| Power consumption (sleep) | 2 W |
| Power consumption (off) | 0.2 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Computer system | |
| Built-in processor | Yes |
| Processor manufacturer | Qualcomm |
| Processor cores | 8 |
| Internal memory | 8 GB |
| Internal storage capacity | 64 GB |
| Operating system installed | Android |
| Operating system version | Android 14 |
| Weight & dimensions | |
| Display width | 252.9 mm |
| Display depth | 22.1 mm |
| Display height | 169 mm |
| Display weight | 1.4 kg |
| Packaging data | |
| Package width | 320 mm |
| Package depth | 150 mm |
| Package height | 235 mm |
| Package weight | 3.6 kg |
| Packaging content | |
| Cables included | Power |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 50 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Certificates | |
| Certification | UL/cUL (US) FCC (US) IC (Canada) CE (Europe) CB (International) VCCI, MIC (Japan) RCM (Australia) |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| Other features | |
| Megapixel (approx.) | 8 MP |
| Built-in camera | Yes |
