Security Camera Axis 02349-001 IP Wired Indoor Outdoor - 02349-001
Security Camera Axis 02349-001 IP Wired Indoor Outdoor - 02349-001
Businesses looking to enhance their security infrastructure can rely on the Axis 02349-001 security camera for comprehensive monitoring in both indoor and outdoor environments. This wired IP camera is ideal for installers and security administrators who need reliable surveillance solutions.
With robust support for multiple languages including English, German, and Spanish, the Axis 02349-001 offers flexibility in deployment for diverse environments. It is engineered to meet rigorous standards such as EN 55032 and EN 61000-6-1, ensuring smooth operation within complex security systems.
- Camera Type: IP security camera
- Deployment: Indoor & outdoor
- Connection: Wired
- Language Support: Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese
- Certifications: EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A
- Mounting Options: Ceiling/wall
Perfect for security teams overseeing facilities needing advanced monitoring solutions across various settings, from retail locations to corporate buildings.
Available stock: 10
-
Estimated delivery: Oct 03 - Oct 07
Share this product
Couldn't load pickup availability
Informations
Informations
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
| Performance | |
|---|---|
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 12 |
| Languages support | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian |
| Certification | EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), KS C 9832 Class A, KS C 9835, RCM AS/NZS CISPR 32 Class A, VCCI Class A |
| Design | |
| Form factor | Box |
| Mounting type | Ceiling/wall |
| Product colour | White |
| LED indicators | Yes |
| Housing material | Aluminium, Plastic |
| Camera | |
| Minimum illumination | 0.03 lx |
| Lens viewing angle, horizontal | 103° |
| Lens viewing angle, vertical | 55° |
| Camera shutter speed | 1/19000 s |
| Image sensor | |
| Number of sensors | 1 |
| Optical sensor size | 25.4 / 2.9 mm (1 / 2.9") |
| Sensor type | CMOS |
| Lens system | |
| Number of lenses | 1 |
| Fixed focal length | 3.16 mm |
| Night vision | |
| Night vision | Yes |
| Video | |
| Maximum resolution | 1920 x 1080 pixels |
| Video compression formats | AVC, H.264, H.265, HEVC, M-JPEG |
| Supported graphics resolutions | 320 x 240, 640 x 360, 1280 x 960, 1920 x 1080 (HD 1080) |
| Supported video modes | 1080p |
| Frame rate | 30 fps |
| Video intelligence analytic | Yes |
| Video streaming | Yes |
| Image quality adjustment | Brightness, Colour depth, Contrast, Saturation, Sharpness |
| Privacy masking | Yes |
| Text caption overlay | Yes |
| Bit rate control | Variable Bit Rate (VBR) |
| Network | |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.1x |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, NTP, NTS, RTSP, RTCP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, SSH, LLDP, MQTT v3.1.1, Syslog, Link-Local-Adresse (ZeroConf) |
| Quality of Service (QoS) support | Yes |
| Storage | |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC |
| Flash memory | 512 MB |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
| IP address filtering | Yes |
| Security algorithms | EAP-TLS, HTTPS, SNMP |
| Power | |
| Power source type | PoE |
| Power consumption (typical) | 2.2 W |
| Power consumption (max) | 4.3 W |
| Power consumption (Power over Ethernet (PoE)) | 4.3 W |
| DC output voltage | 12 |
| DC output current | 2.5 A |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width | 60 mm |
| Depth | 93 mm |
| Height | 105 mm |
| Weight | 137 g |
| Packaging content | |
| Number of cameras | 1 |
