Tripp Lite SMART1500LCD uninterruptible power supply (UPS)
Tripp Lite SMART1500LCD uninterruptible power supply (UPS)Available stock: 31
-
Estimated delivery: Oct 07 - Oct 11
Share this product
Couldn't load pickup availability
Infomations
Infomations
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
| Features | |
|---|---|
| UPS topology | Line-Interactive |
| Output power capacity | 1.5 kVA |
| Output power | 900 W |
| Waveform | Sine |
| Input operation voltage (min) | 75 V |
| Input operation voltage (max) | 147 V |
| Input frequency | 60 Hz |
| Output operation voltage (min) | 115 V |
| Output operation voltage (max) | 120 V |
| Automatic Voltage Regulation (AVR) | Yes |
| Maximum current | 8.5 A |
| Surge energy rating | 480 J |
| Number of input phases | 1 |
| Efficiency | 92% |
| EMI/RFI noise filtering | Yes |
| Audible alarm(s) | Yes |
| Ports & interfaces | |
| AC outlet types | NEMA 5–15R |
| Power plug | NEMA 5-15P |
| AC outlets quantity | 8 AC outlet(s) |
| USB 2.0 ports quantity | 1 |
| Serial ports quantity | 1 |
| Battery | |
| Typical backup time at full load | 3.5 min |
| Typical backup time at half load | 13 min |
| Battery recharge time | 4.5 h |
| Design | |
| Form factor | Rackmount/Tower |
| Housing material | Acrylonitrile butadiene styrene (ABS) |
| Rack capacity | 2U |
| Cable length | 1.8 m |
| Cooling type | Active |
| Product colour | Black |
| Display type | LCD |
| LED indicators | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 50 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Weight & dimensions | |
| Width | 438.2 mm |
| Depth | 266.7 mm |
| Height | 88.9 mm |
| Weight | 13.6 kg |
| Packaging data | |
| Package width | 378.5 mm |
| Package depth | 541 mm |
| Package height | 198.1 mm |
| Package weight | 13.9 kg |
| Logistics data | |
| Master (outer) case width | 378.5 mm |
| Master (outer) case length | 541 mm |
| Master (outer) case height | 180.3 mm |
| Master (outer) case gross weight | 14.5 kg |
| Products per master (outer) case | 1 pc(s) |
| Country of origin | China |
| Other features | |
| Non-operating relative humidity (non-condensing) | 0 - 95% |
| Weight (imperial) | 13.2 kg (29 lbs) |
