Management features
Switch type Unmanaged
Switch layer L2
Quality of Service (QoS) support Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 24
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity 24
Combo SFP ports quantity 2
Network
Networking standards IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support No
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T
Full duplex Yes
Half duplex Yes
Flow control support Yes
Auto MDI/MDI-X Yes
Head-of-line (HOL) blocking Yes
Ethernet LAN data rates 10,100,1000 Mbit/s
Data transmission
Switching capacity 48 Gbit/s
Forwarding rate 35.7 Mpps
MAC address table 8192 entries
Number of queues 4
Jumbo frames support Yes
Jumbo frames 9216
Security
Queue scheduling algorithms Weighted Round Robin (WRR)
Design
Rack mounting Yes
Form factor 1U
Product colour Grey
LED indicators Yes
Performance
Built-in processor Yes
Processor frequency 400 MHz
Internal memory 64 MB
Flash memory 8 MB
Mean time between failures (MTBF) 524296 h
Power
Power supply included Yes
Redundant power supply (RPS) support No
Number of power supply units 1
AC input voltage 110 - 240 V
AC input frequency 50 - 60 Hz
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -20 - 70 °C
Operating relative humidity (H-H) 10 - 90%
Storage relative humidity (H-H) 5 - 90%
Heat dissipation 55.75 BTU/h
Weight & dimensions
Width 279 mm
Depth 170 mm
Height 44 mm
Weight 1.56 kg
Packaging content
Quick start guide Yes
Rack mount kit Yes
Sustainability
Sustainability compliance Yes
Certificates
Compliance certificates CE
Certification UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, FCC Class B
Logistics data
Harmonized System (HS) code 85176990
