Management features
Switch type Managed
Switch layer L2
Web-based management Yes
Configuring Location Settings (CLI) Yes
System event log Yes
MIB support RFC 1066, RFC 1213, 1157, RFC 1493, RFC 1643, RFC 1757, RFC 2011, 2012, 2013, RFC 2233, RFC 2358, RFC 2674, RFC 2819, 2925, RFC 3621, RFC 4293, RFC 4292, RFC 4022, RFC 4113
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 10
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
SFP module slots quantity 2
Network
Networking standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support No
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring Yes
Flow control support Yes
Broadcast storm control Yes
Spanning tree protocol Yes
VLAN support Yes
Virtual LAN features MAC address-based VLAN, Port-based VLAN
Number of VLANs 256
Optical fiber
Fiber ethernet cabling technology 1000BASE-X
Data transmission
Switching capacity 24 Gbit/s
Forwarding rate 17.8 Mpps
MAC address table 8000 entries
Packet buffer memory 0.525 MB
Security
DHCP features DHCP client, DHCP relay, DHCP snooping
IGMP snooping Yes
IGMP proxy Yes
Security algorithms SNMP, SNMPv3, SSH, SSL/TLS
MAC address filtering Yes
Loop protection Yes
Queue scheduling algorithms SPQ, WFQ, Weighted Round Robin (WRR)
Multicast features
Multicast support Yes
Design
Rack mounting Yes
Product colour Grey
LED indicators Yes
Performance
Noise level 27.3 dB
Firmware upgradeable Yes
Mean time between failures (MTBF) 1065025.45 h
Power
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Power consumption (max) 160.3 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) ports quantity 8
Total Power over Ethernet (PoE) budget 130 W
Operational conditions
Operating temperature (T-T) -20 - 50 °C
Storage temperature (T-T) -40 - 70 °C
Operating relative humidity (H-H) 5 - 95%
Storage relative humidity (H-H) 5 - 95%
Heat dissipation 546.62 BTU/h
Weight & dimensions
Width 267 mm
Depth 162 mm
Height 44 mm
Weight 1.63 kg
Packaging content
Cables included AC
Rack mount kit Yes
Logistics data
Harmonized System (HS) code 85176990
