Storage
Storage drive capacity 0 GB
Supported storage drive interfaces Serial ATA III, Serial ATA II
Storage drive sizes supported 2.5,3.5"
Number of M.2 (M & B) slots 2
RAID support Yes
RAID levels 0, 1, 5, 10, 50, 60, JBOD
Online RAID migration Yes
Online RAID expansion Yes
RAID rebuild Yes
Hot-swap drive bays Yes
Supported file systems FAT32, HFS+, NTFS, ZFS, exFAT, ext3, ext4
Storage drives installed No
Total installed storage capacity 0 TB
Number of storage drives supported 8
Installed storage drive type No
Supported storage drive types HDD & SSD
Disk roaming Yes
Processor
Processor manufacturer Intel
Processor family Intel Atom®
Processor model C5125
Processor frequency 2.8 GHz
Processor cores 8
Processor threads 8
Processor cache 9 MB
Number of processors installed 1
ECC supported by processor Yes
Thermal Design Power (TDP) 50 W
Memory
Internal memory 8 GB
Internal memory type DDR4
Maximum RAM supported 64 GB
Memory slots 2
Memory form factor SO-DIMM
Flash memory 5000 MB
Network
Ethernet LAN Yes
Ethernet LAN data rates 10,100,1000,2500 Mbit/s
DHCP server Yes
Jumbo frames support Yes
iSCSI support Yes
Wake-on-LAN ready Yes
Supported network protocols IPv4, IPv6
Dynamic DNS (DDNS) Yes
Ports & interfaces
USB port Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4
Fiber optic connector MTP
Ethernet LAN (RJ-45) ports 2
PCI Express x4 (Gen 3.x) slots 2
Design
Chassis type Rack (2U)
Cooling type Active
Product colour Black
Number of fans 3 fan(s)
Fan diameter 6 cm
LED indicators Yes
Performance
Type NAS
Device class Small & Medium Business
Backup function Yes
Backup features USB drive, iSCSI LUN
Buzzer Yes
Snapshot Yes
Management protocols SNMP V2, V3
Security algorithms AES, FIPS 140, HTTPS, SSH
Access Control List (ACL) Yes
Reset button Yes
On/off switch Yes
Built-in FTP server Yes
Browser supported Apple Safari (latest version) Google Chrome (latest version) Microsoft Edge (latest version) Mozilla Firefox (latest version)
System log Yes
Hot spare Yes
S.M.A.R.T. support Yes
Share folder CIFS/SMB
USB copy function Yes
Software
Operating system installed QuTS hero
Operating system version h5.0.1
Windows operating systems supported Windows 10, Windows 11, Windows 7, Windows 8
Linux operating systems supported CentOS 7.0, Ubuntu 14.04, Yes
Mac operating systems supported Mac OS X 10.10 Yosemite, Yes
Server operating systems supported Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Other operating systems supported IBM AIX 7.1, Solaris 10
Power
Power supply location Built-in
Power supply unit (PSU) capacity 250 W
Number of power supply units 1
Power consumption (typical) 79.113 W
Power consumption (sleep) 49.799 W
AC input voltage 100 - 240 V
Fan voltage 12 V
Weight & dimensions
Width 432 mm
Depth 297.4 mm
Height 88.6 mm
Weight 7.61 kg
Package width 530 mm
Package depth 210 mm
Package height 592 mm
Package weight 10.9 kg
Packaging content
Cables included AC, LAN (RJ-45)
Power cables quantity 1
Quick installation guide Yes
Number of screws 56
Package type Box
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 5 - 95%
Storage temperature (T-T) -20 - 70 °C
Other features
Fibre Channel Yes
Warranty period 3 year(s)
