Features
2.4 GHz Yes
5 GHz Yes
Maximum data transfer rate 1487 Mbit/s
Maximum data transfer rate (2.4 GHz) 287 Mbit/s
Maximum data transfer rate (5 GHz) 1200 Mbit/s
Ethernet LAN data rates 1000,5000 Mbit/s
Frequency band 20/40 (2.4 GHz), 20/40/80 (5 GHz), maximum peak data rate 1.49 Gbps
Networking standards IEEE 802.11ax, IEEE 802.11mc
Bluetooth Yes
Bluetooth version 5.0
Auto MDI/MDI-X Yes
MIMO Yes
MIMO type Multi User MIMO
Spread spectrum method DSSS, OFDM, OFDMA
Modulation 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK
MACsec support No
Security
Security algorithms WPA2, WPA3
Management features
Access point management On-premises; Public Cloud; Virtual Private Cloud (VPC); as a Service
Ports & interfaces
Ethernet LAN (RJ-45) ports 2
USB connector type Micro-USB B
Power
Power over Ethernet (PoE) Yes
Power consumption (typical) 10 W
Design
Placement Table, Wall
Product colour White
Recommended usage Indoor
Antenna
Antenna type Internal
Antenna direction type Semi-directional
Antenna features Integrated antenna
Antennas quantity 2
Antenna gain level (max) 5.6 dBi
Performance
Compatible operating systems HPE Aruba Networking Operating System and HPE Aruba Networking Instant OS 8.7.1.0 (AP-503H) and 8.7.0.0 (AP-505H), HPE Aruba Networking Operating System 10.3.0.0 (AP-503H), 10.2.0.0 (AP-505H)
Certificates
Compliance certificates Federal Communications Commission (FCC), ISED, CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Certification Wi‑Fi Alliance: Wi-Fi CERTIFIED a, b, g, n, ac Wi-Fi CERTIFIED 6 (ax) WPA, WPA2 and WPA3–Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, Wi-Fi Agile Multiband Wi-Fi CERTIFIED Location (AP-505H only) Bluetooth SIG Ethernet Alliance (PoE)
Weight & dimensions
Width 86 mm
Depth 47 mm
Height 150 mm
Weight 360 g
Other features
I/O ports 1 x 10/100/1000BASE-T RJ-45 port, auto-sensing link speed and MDI/MDX 4 x 10/100/1000BASE-T (RJ-45) ports, auto-sensing link speed and MDI/MDX
Weight (imperial) 0.363 kg (0.8 lbs)
Operational conditions
Operating relative humidity (H-H) 5 - 93%
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 5 - 93%
Logistics data
Harmonized System (HS) code 85176990
