Management features
Switch type Managed
Switch layer L2/L3
Quality of Service (QoS) support Yes
Traffic classification Yes
System event log Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 24
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity 4
Fiber optic connector SFP+
Network
Networking standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
10G support Yes
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported Cat5, Cat5e
Port mirroring Yes
Full duplex Yes
Flow control support Yes
Link aggregation Yes
Broadcast storm control Yes
Auto MDI/MDI-X Yes
Spanning tree protocol Yes
Head-of-line (HOL) blocking Yes
Auto-negotiation Yes
MAC address auto-learning supported Yes
VLAN support Yes
Virtual LAN features Tagged VLAN, Protocol-based VLAN
Number of VLANs 4094
Data transmission
Switching capacity 128 Gbit/s
Throughput 95.24 Mpps
MAC address table 16384 entries
Store-and-forward Yes
Number of queues 8
Jumbo frames support Yes
Jumbo frames 9216
Packet buffer memory 1.5 MB
Security
DHCP features DHCP server, DHCP client
Access Control List (ACL) Yes
Access Control List (ACL) rules 768
IGMP snooping Yes
Security algorithms 802.1x RADIUS, EAP, SNMP, SSH, SSH-2, SSL/TLS
SSH/SSL support Yes
BPDU filtering/protection Yes
Authentication MAC-based authentication, Port-based authentication
Multicast features
Multicast support Yes
Design
Rack mounting Yes
Stackable Yes
Product colour Black, Grey
LED indicators Activity, Link, PoE, Power, Speed
Number of fans 2 fan(s)
Safety cUL, CB
Performance
Built-in processor Yes
Processor frequency 400 MHz
Internal memory 256 MB
Flash memory 32 MB
Mean time between failures (MTBF) 274796 h
Power
Power source AC
Power supply included Yes
AC input voltage 100 - 240 V
Power consumption (max) 436.3 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) ports quantity 24
Power over Ethernet (PoE) power per port 30 W
Total Power over Ethernet (PoE) budget 370 W
Operational conditions
Operating temperature (T-T) -5 - 50 °C
Storage temperature (T-T) -20 - 70 °C
Operating relative humidity (H-H) 0 - 95%
Storage relative humidity (H-H) 0 - 95%
Heat dissipation 1487.78 BTU/h
Weight & dimensions
Width 440 mm
Depth 308.5 mm
Height 44 mm
Weight 4.25 kg
Packaging data
Package width 450 mm
Package depth 510 mm
Package height 121 mm
Package weight 7.06 kg
Technical details
Shipping (inner) case height 48.5 cm
Shipping (inner) case width 38.5 cm
Shipping (inner) case length 53 cm
Shipping (inner) case net weight 14.3 kg
Products per shipping (inner) case 3 pc(s)
Pallet gross weight (air) 561.6 kg
Master (outer) cases per pallet (air) 24 pc(s)
Products per pallet (air) 72 pc(s)
Pallet gross length 110 cm
Pallet gross width 120 cm
Pallet height (air) 2.08 m
Pallet gross weight (sea) 561.6 kg
Master (outer) cases per pallet (sea) 24 pc(s)
Products per pallet (sea) 72 pc(s)
Pallet height (sea) 2.08 m
Shipping (inner) case gross weight 22.6 kg
Logistics data
Harmonized System (HS) code 85176990
