Ports & interfaces
Host interface PCIe
Output interface Serial
Expansion card form factor Full-height / Low-profile
Serial ports quantity 8
Serial interface type RS-232
Design
Internal Yes
Product colour Yellow
Certification CE, FCC, TAA
Features
Chipset ASMEDIA - ASM1083, SYSTEMBASE - SB16C1058PCI
Baud rate 926.1 Kbit/s
FIFO (First In, First Out) 256 B
Data bits 5, 6, 7, 8
Stop bits 1, 1.5, 2
Flow control support Yes
Parity bit Even, No, Odd
Flow Control type RTS/CTS, XON/XOFF
Operational conditions
Operating temperature (T-T) 0 - 55 °C
Storage temperature (T-T) -20 - 85 °C
Operating relative humidity (H-H) 5 - 95%
System requirements
Windows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 2000, Windows 2000 Professional, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows CE, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Linux operating systems supported Yes
Server operating systems supported Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2016, Windows Server 2019
Technical details
Compliance certificates RoHS
Weight & dimensions
Width 22 mm
Depth 145 mm
Height 60 mm
Weight 116 g
Packaging data
Quantity 1
Cables included Serial
Mounting brackets included Yes
User guide Yes
Package width 190 mm
Package depth 290 mm
Package height 70 mm
Package weight 750 g
Logistics data
Harmonized System (HS) code 84733020
Products per master (outer) case 14 pc(s)
Master (outer) case width 400 mm
Master (outer) case length 510 mm
Master (outer) case height 315 mm
